My insights from OpenStack “what is core” Spider > we need pluggable architectures

THIS POST IS #3 IN A SERIES ABOUT “WHAT IS CORE.”

IdeasSo what did we learn from the spider map exercise?  Above all else, the spider confirmed that to me that OpenStack is a world of paradox.  The perfect definition of core may be elusive, but I believe we can find one that is sufficient.

The goal was understanding not philosophical truth.  In a diverse and vibrant community with many objectives, understanding leads to consensus while being “right” can become very lonely.

Since our goal was not to answer the question, what did we want to accomplish?  Spider success was defined as creating a framework, really a list of agreed positions (post #4), that narrows the scope of the “what is core” dialog.

Too vague a framework leads to uncertainty about what’s included, stable and working while too rigid a baseline could drive away innovation and lead to forking.  Being too aggressively open could discourage commercial investment yet too proprietary an approach contradicts our collaboration and community values.

Having a workable framework that accommodates these diverse positions allows us to move forward.

So what did Alan and I learn from the spider to help the discussion?

  • “Plug-ins” are essential to the definition of core because they create safe places for innovation  [note: there has been much refinement of what "plug-in" means here]
  • It is possible to balance between stability and innovation if we have a way to allow implementations to evolve
  • OpenStack has a significant commercial ecosystem that needs to be accommodated in core
  • We need an approach that allows extension and improvement without having to incubate new projects
  • We need to ensure that we use brand and culture to combat forking
  • Interoperability is a worthy goal
  • Everyone thinks testing is good, but it’s still a sidebar
  • There are multiple distinct audiences with conflicting goals: some want stability and durability while others want innovation and flexibility.

Of these insights, the need to discuss how OpenStack promotes a plug-in architecture seemed address the most points of tension.  [update: in the course of discussion, we've defining plug-in more generally to be something like "a designated section of implementation code that can be altered without negatively changing the base function of the project."]

This is not the only item worth discussing, but it was the one that made the most sense to cover first based on the spider map.  Our idea was that having the community find agreement on how we approach plug-ins would lead us closer to a common ground for the “what is core” discussion.

Finding a common thread shrinks the problem space so the Board, TC and Community can advance in discussion.  So far, that assessment has proven accurate enough to move the dialog forward.

READ POST IS #4: TWELVE POSITIONS

DevOps approaches to upgrade: Cube Visualization

I’m working on my OpenStack summit talk about DevOps upgrade patterns and got to a point where there are three major vectors to consider:

  1. Step Size (shown as X axis): do we make upgrades in small frequent steps or queue up changes into larger bundles? Larger steps mean that there are more changes to be accommodated simultaneously.
  2. Change Leader (shown as Y axis): do we upgrade the server or the client first? Regardless of the choice, the followers should be able to handle multiple protocol versions if we are going to have any hope of a reasonable upgrade.
  3. Safeness (shown as Z axis): do the changes preserve the data and productivity of the entity being upgraded? It is simpler to assume to we simply add new components and remove old components; this approach carries significant risks or redundancy requirements.

I’m strongly biased towards continuous deployment because I think it reduces risk and increases agility; however, I laying out all the vertices of the upgrade cube help to visualize where the costs and risks are being added into the traditional upgrade models.

Breaking down each vertex:

  1. Continuous Deploy – core infrastructure is updated on a regular (usually daily or faster) basis
  2. Protocol Driven – like changing to HTML5, the clients are tolerant to multiple protocols and changes take a long time to roll out
  3. Staged Upgrade – tightly coordinate migration between major versions over a short period of time in which all of the components in the system step from one version to the next together.
  4. Rolling Upgrade – system operates a small band of versions simultaneously where the components with the oldest versions are in process of being removed and their capacity replaced with new nodes using the latest versions.
  5. Parallel Operation – two server systems operate and clients choose when to migrate to the latest version.
  6. Protocol Stepping – rollout of clients that support multiple versions and then upgrade the server infrastructure only after all clients have achieved can support both versions.
  7. Forced Client Migration – change the server infrastructure and then force the clients to upgrade before they can reconnect.
  8. Big Bang – you have to shut down all components of the system to upgrade it

This type of visualization helps me identify costs and options. It’s not likely to get much time in the final presentation so I’m hoping to hear in advance if it resonates with others.

PS: like this visualization? check out my “magic 8 cube” for cloud hosting options.

Continuous Release combats disruptions of “Free Fall” development

Since I posted the “Free Fall” development post, I’ve been thinking a bit about the pros and cons of this type of off-release development.

The OpenStack Swift project does not do free fall because they are on a constant “ship ready” state for the project and only loosely flow the broader OpenStack release track.  My team at Dell also has minimal free fall development because we have a more frequent release clock and choose to have the team focus together through dev/integrate/harden cycles as much as possible.

From a Lean/Agile/CI perspective, I would work to avoid hidden development where possible.  New features are introduced by split test (they are in the code, but not active for most users) so that the all changes in incremental.  That means that refactoring, rearchitecture and new capabilities appear less disruptively.  While it may this approach appears to take more effort in the short term; my experience is that it accelerates delivery because we are less likely to over develop code.

Unfortunately, free fall development has the opposite effect.  Having code that appears in big blocks is contrary to best practices in my opinion.  Further, it rewards groups that work asynchronously and

While I think that OpenStack benefits from free fall work, I think that it is ultimately counter-productive.

Why doesn’t Chef call them “bowls” instead of roles?

The extended Crowbar team (my employer Dell and community) recently had a bit of a controversy heated discussion over the renaming of “proposals” to “configurations.” It was pretty clear that the term “proposal” confused users because an “active proposal” seems like a bit of an oxymoron. Excepting Scott Jensen, our schedule-czar and director of engineering, we had relatively few die-hard “I love proposal” advocates; however, deciding on an alternative was not quite so easy.

Ultimately, the question came down to “do we use an invented term or an intuitive term.”  The answer lies in when to use or avoid the congruity theory as articulated by Roger Cauvin.

We considered many alternatives like calling them “fixtures” to go along with the Crowbar & Barclamp tool theme. Even “Chuck Norris” was considered until copyright issues were flagged. The top alternative, “configuration” seemed just too bland. Frankly and amazingly, we originally considered it “too descriptive!”

The crux of the argument really revolved around the users’ ability to intuitively grasp a concept or to force them learn a new term. For example, we specifically chose “barclamp” instead of “module” because we felt that there were more components to a barclamp than just being a Crowbar module. In many ways, module would be sufficiently descriptive; however, we saw that there was benefit to the user tax in introducing a new term. It also fit nicely within our tool theme.

Opscode Chef is an example of investing heavily in a naming theme. For example, the concept of “cookbooks” and “recipes” seems relatively intuitive for users but starts getting stretched for “knife” because it is not immediately clear to users what that component does (it executes instructions on nodes and the server). After learning Chef, I appreciate “knife” as the universal tool but still remember having to figure it out.

A good theme is awesome, but it can quickly encumber usability.

For example, what if Chef has used “bowl” instead of role. It’s logical: you put a group of ingredients to mix into a bowl that acts as a container. While it may be logical to the initiated, it mainly extends the learning curve for new users. A role is a commonly accepted term for an operational classification so it is a much better term for users. The same is true for “node” and “data bag.”

I love a good incongruent theme as much as any meme-enabled tech geek but themes must not hinder usability. After all, we all fight for the users.

The real workloads begin: Crowbar’s Sophomore Year

Given Crowbar‘s frenetic Freshman year, it’s impossible to predict everything that Crowbar could become. I certainly aspire to see the project gain a stronger developer community and the seeds of this transformation are sprouting. I also see that community driven work is positioning Crowbar to break beyond being platforms for OpenStack and Apache Hadoop solutions that pay the bills for my team at Dell to invest in Crowbar development.

I don’t have to look beyond the summer to see important development for Crowbar because of the substantial goals of the Crowbar 2.0 refactor.

Crowbar 2.0 is really just around the corner so I’d like to set some longer range goals for our next year.

  • Growing acceptance of Crowbar as an in data center extension for DevOps tools (what I call CloudOps)
  • Deeper integration into more operating environments beyond the core Linux flavors (like virtualization hosts, closed and special purpose operating systems.
  • Improvements in dynamic networking configuration
  • Enabling more online network connected operating modes
  • Taking on production ops challenges of scale, high availability and migration
  • Formalization of our community engagement with summits, user groups, and broader developer contributions.

For example, Crowbar 2.0 will be able to handle downloading packages and applications from the internet. Online content is not a major benefit without being able to stage and control how those new packages are deployed; consequently, our goals remains tightly focused improvements in orchestration.

These changes create a foundation that enables a more dynamic operating environment. Ultimately, I see Crowbar driving towards a vision of fully integrated continuous operations; however, Greg & Rob’s Crowbar vision is the topic for tomorrow’s post.

Community Participation in Crowbar 2.0 Efforts

I’ve laid out the Dell Crowbar team‘s technical objectives for Crowbar 2.0. Now it’s time to lay out how we plan to involve the Crowbar community. We welcome community participation and contributions but, I’m not making any pretense here, that refactoring must also satisfy needs expressed by the “Dell OpenStack powered Cloud” and “Dell | Cloudera Apache Hadoop” solutions. There is a happy alignment between Dell’s needs and our community’s since both of these solutions are openly developed.

Our community played a substantial role in the definition of Crowbar 2.0. We have been watching and listening carefully and the majority of the changes will leverage recommendations and address concerns raised by Crowbar users.

The Dell Crowbar team has been working towards Crowbar 2 for quite a while. Networking and operating system code is already in place and our team began design requirements for the refactoring mid-June.

Community Communication

We have setup the following meeting for community engagement around the Crowbar refactoring. Our purpose is to enable development collaboration during the refactoring – these will not be “learning Crowbar” sessions.

  • Design Brief (2 hour meeting)
    • Objective: Review by of design and refactoring plans in progress by Dell Crowbar team. Provide basis for community input and discussion during week.
    • When: Monday 7/16 at 10am CDT
    • Where: Online Session
    • Who: Anyone (this is a listening session, not a discussion event)
  • Design Summit (4+2 hour meeting)
    • Objective: Provide input and suggestions about design proposal (see preparation). Identify members of collaboration teams for refactoring effort.
    • Preparation: Attend 7/16 Design Brief & Complete Expert Homework.
    • When: Friday 7/20
    • Where: OSCON 2012 in Portland (not on-site at OSCON). To facilitate face-to-face dialog, there will be no interactive online component.
    • Who: 20 people, invitation only due to space limitations. Attendees representing DevOps tools, hosting companies, operating system vendors, Hadoop & OpenStack contributors
    • Notes will be posted
  • Follow-up sessions
    • Objective: Coordinate delivery of refactored code
    • When: Likely weekly following Summit
    • Where: Online (Skype or Google Hangout)
    • Who: Crowbar Developers

Of course, we will continue to engage on the Crowbar list and Skype channels.

More on the 7/20 Design Summit

The purpose of the summit is strictly limited to discussing and organizing efforts around Crowbar 2.0 refactoring. To maintain a tight focus on this effort, we made the decision to limit the audience of this event by making it in-person and invitation only.

The Summit is not a broad discussion about Crowbar’s future with an open space format. We have a specific need and agenda – coordinating the development of 2.0. For that reason, we made to decision to restrict invitations to partners who are ready to commit substantial effort towards Crowbar development in the next 6 months. This is a technical session only: attendees must have first-hand experience coding Crowbar, be able to build the code and take on development or test commitments.

Because of the time limitations, we are holding a mandatory pre-summit brief about the design changes. This session will be open for the community and we welcome comments.

The agenda for the Design Summit is as follows:

  • 8:30 (45 mins): Crowbar 2.0 Challenges & Objectives
  • 9:15 (30 mins): Packaging and Delivery
  • 9:45 (15 mins) Break
  • 10:00 (30 mins): Networking
  • 10:30 (30 mins): Data Representation and Framework
  • 11:00 (30 mins): Next Steps, Future meetings & work assignments
  • 11:30 official content ends & lunch
  • 12:00 (30 mins) breakout sessions based on discussions above, TBD during summit
  • 12:30 (30 mins) breakout sessions based on discussions above, TBD during summit
  • 1:00 (30 mins) breakout sessions based on discussions above, TBD during summit
  • 1:30 (30 mins) breakout sessions based on discussions above, TBD during summit
  • 2:00 meeting ends

Post Script: A Community Design Summit

We have already begun discussing a true community summit with an open agenda. That summit will likely be a dedicated event in Austin, Texas with 2 (or more!) days of content. Please let me know if this is of interest to you so we can begin building the business case for hosting it!

Our Vision for Crowbar – taking steps towards closed loop operations

When Greg Althaus and I first proposed the project that would become Dell’s Crowbar, we had already learned first-hand that there was a significant gap in both the technologies and the processes for scale operations. Our team at Dell saw that the successful cloud data centers were treating their deployments as integrated systems (now called DevOps) in which configuration of many components where coordinated and orchestrated; however, these approaches feel short of the mark in our opinion. We wanted to create a truly integrated operational environment from the bare metal through the networking up to the applications and out to the operations tooling.

Our ultimate technical nirvana is to achieve closed-loop continuous deployments. We want to see applications that constantly optimize new code, deployment changes, quality, revenue and cost of operations. We could find parts but not a complete adequate foundation for this vision.

The business driver for Crowbar is system thinking around improved time to value and flexibility. While our technical vision is a long-term objective, we see very real short-term ROI. It does not matter if you are writing your own software or deploying applications; the faster you can move that code into production the sooner you get value from innovation. It is clear to us that the most successful technology companies have reorganized around speed to market and adapting to pace of change.

System flexibility & acceleration were key values when lean manufacturing revolution gave Dell a competitive advantage and it has proven even more critical in today’s dynamic technology innovation climate.

We hope that this post helps define a vision for Crowbar beyond the upcoming refactoring. We started the project with the idea that new tools meant we could take operations to a new level.

While that’s a great objective, we’re too pragmatic in delivery to rest on a broad objective. Let’s take a look at Crowbar’s concrete strengths and growth areas.

Key strength areas for Crowbar

  1. Late binding – hardware and network configuration is held until software configuration is known.  This is a huge system concept.
  2. Dynamic and Integrated Networking – means that we treat networking as a 1st class citizen for ops (sort of like software defined networking but integrated into the application)
  3. System Perspective – no Application is an island.  You can’t optimize just the deployment, you need to consider hardware, software, networking and operations all together.
  4. Bootstrapping (bare metal) – while not “rocket science” it takes a lot of careful effort to get this right in a way that is meaningful in a continuous operations environment.
  5. Open Source / Open Development / Modular Design – this problem is simply too complex to solve alone.  We need to get a much broader net of environments and thinking involved.

Continuing Areas of Leadership

  1. Open / Lean / Incremental Architecture – these are core aspects of our approach.  While we have a vision, we also are very open to ways that solve problems faster and more elegantly than we’d expected.
  2. Continuous deployment – we think the release cycles are getting faster and the only way to survive is the build change into the foundation of operations.
  3. Integrated networking – software defined networking is cool, but not enough.  We need to have semantics that link applications, networks and infrastructure together.
  4. Equilivent physical / virtual – we’re not saying that you won’t care if it’s physical or virtual (you should), we think that it should not impact your operations.
  5. Scale / Hybrid - the key element to hybrid is scale and to hybrid is scale.  The missing connection is being able to close the loop.
  6. Closed loop deployment – seeking load management, code quality, profit, and cost of operations as factor in managed operations.

Crowbar 2.0 Objectives: Scalable, Heterogeneous, Flexible and Connected

The seeds for Crowbar 2.0 have been in the 1.x code base for a while and were recently accelerated by SuSE.  With the Dell | Cloudera 4 Hadoop and Essex OpenStack-powered releases behind us, we will now be totally focused bringing these seeds to fruition in the next two months.

Getting the core Crowbar 2.0 changes working is not a major refactoring effort in calendar time; however, it will impact current Crowbar developers by changing improving the programming APIs. The Dell Crowbar team decided to treat this as a focused refactoring effort because several important changes are tightly coupled. We cannot solve them independently without causing a larger disruption.

All of the Crowbar 2.0 changes address issues and concerns raised in the community and are needed to support expanding of our OpenStack and Hadoop application deployments.

Our technical objective for Crowbar 2.0 is to simplify and streamline development efforts as the development and user community grows. We are seeking to:

  1. simplify our use of Chef and eliminate Crowbar requirements in our Opscode Chef recipes.
    1. reduce the initial effort required to leverage Crowbar
    2. opens Crowbar to a broader audience (see Upstreaming)
  2. provide heterogeneous / multiple operating system deployments. This enables:
    1. multiple versions of the same OS running for upgrades
    2. different operating systems operating simultaneously (and deal with heterogeneous packaging issues)
    3. accommodation of no-agent systems like locked systems (e.g.: virtualization hosts) and switches (aka external entities)
    4. UEFI booting in Sledgehammer
  3. strengthen networking abstractions
    1. allow networking configurations to be created dynamically (so that users are not locked into choices made before Crowbar deployment)
    2. better manage connected operations
    3. enable pull-from-source deployments that are ahead of (or forked from) available packages.
  4. improvements in Crowbar’s core database and state machine to enable
    1. larger scale concerns
    2. controlled production migrations and upgrades
  5. other important items
    1. make documentation more coupled to current features and easier to maintain
    2. upgrade to Rails 3 to simplify code base, security and performance
    3. deepen automated test coverage and capabilities

Beyond these great technical targets, we want Crowbar 2.0 is to address barriers to adoption that have been raised by our community, customers and partners. We have been tracking concerns about the learning curve for adding barclamps, complexity of networking configuration and packaging into a single ISO.

We will kick off to community part of this effort with an online review on 7/16 (details).

PS: why a refactoring?

My team at Dell does not take on any refactoring changes lightly because they are disruptive to our community; however, a convergence of requirements has made it necessary to update several core components simultaneously. Specifically, we found that desired changes in networking, operating systems, packaging, configuration management, scale and hardware support all required interlocked changes. We have been bringing many of these changes into the code base in preparation and have reached a point where the next steps require changing Crowbar 1.0 semantics.

We are first and foremost an incremental architecture & lean development team – Crowbar 2.0 will have the smallest footprint needed to begin the transformations that are currently blocking us. There is significant room during and after the refactor for the community to shape Crowbar.

Extending Chef’s reach: “Managed Nodes” for External Entities.

Note: this post is very technical and relates to detailed Chef design patterns used by Crowbar. I apologize in advance for the post’s opacity. Just unleash your inner DevOps geek and read on. I promise you’ll find some gems.

At the Opscode Community Summit, Dell’s primary focus was creating an “External Entity” or “Managed Node” model. Matt Ray prefers the term “managed node” so I’ll defer to that name for now. This model is needed for Crowbar to manage system components that cannot run an agent such as a network switch, blade chassis, IP power distribution unit (PDU), and a SAN array. The concept for a managed node is that there is an instance of the chef-client agent that can act as a delegate for the external entity. We’ve been reluctant to call it a “proxy” because that term is so overloaded.

My Crowbar vision is to manage an end-to-end cloud application life-cycle. This starts from power and network connections to hardware RAID and BIOS then up to the services that are installed on the node and ultimately reaches up to applications installed in VMs on those nodes.

Our design goal is that you can control a managed node with the same Chef semantics that we already use. For example, adding a Network proposal role to the Switch managed node will force the agent to update its configuration during the next chef-client run. During the run, the managed node will see that the network proposal has several VLANs configured in its attributes. The node will then update the actual switch entity to match the attributes.

Design Considerations

There are five key aspects of our managed node design. They are configuration, discovery, location, relationships, and sequence. Let’s explore each in detail.

A managed node’s configuration is different than a service or actuator pattern. The core concept of a node in chef is that the node owns the configuration. You make changes to the nodes configuration and it’s the nodes job to manage its state to maintain that configuration. In a service pattern, the consumer manages specific requests directly. At the summit (with apologies to Bill Clinton), I described Chef configuration as telling a node what it “is” while a service provide verbs that change a node. The critical difference is that a node is expected to maintain configuration as its composition changes (e.g.: node is now connected for VLAN 666) while a service responds to specific change requests (node adds tag for VLAN 666). Our goal is the maintain Chef’s configuration management concept for the external entities.

Managed nodes also have a resource discovery concept that must align with the current ohai discovery model. Like a regular node, the manage node’s data attributes reflect the state of the managed entity; consequently we’d expect a blade chassis managed node to enumerate the blades that are included. This creates an expectation that the manage node appears to be “root” for the entity that it represents. We are also assuming that the Chef server can be trusted with the sharable discovered data. There may be cases where these assumptions do not have to be true, but we are making them for now.

Another essential element of managed nodes is that their agent location matters because the external resource generally has restricted access. There are several examples of this requirement. Switch configuration may require a serial connection from a specific node. Blade SANs and PDUs management ports are restricted to specific networks. This means that the manage node agents must run from a specific location. This location is not important to the Chef server or the nodes’ actions against the managed node; however, it’s critical for the system when starting the managed node agent. While it’s possible for managed nodes to run on nodes that are outside the overall Chef infrastructure, our use cases make it more likely that they will run as independent processes from regular nodes. This means that we’ll have to add some relationship information for managed nodes and perhaps a barclamp to install and manage managed nodes.

All of our use cases for managed nodes have a direct physical linkage between the managed node and server nodes. For a switch, it’s the ports connected. For a chassis, it’s the blades installed. For a SAN, it’s the LUNs exposed. These links imply a hierarchical graph that is not currently modeled in Chef data – in fact, it’s completely missing and difficult to maintain. At this time, it’s not clear how we or Opscode will address this. My current expectation is that we’ll use yet more roles to capture the relationships and add some hierarchical UI elements into Crowbar to help visualize it. We’ll also need to comprehend node types because “managed nodes” are too generic in our UI context.

Finally, we have to consider the sequence of action for actions between managed nodes and nodes.  In all of our uses cases, steps to bring up a node requires orchestration with the managed node.  Specifically, there needs to be a hand-off between the managed node and the node.  For example, installing an application that uses VLANs does not work until the switch has created the VLAN,  There are the same challenges on LUNs and SAN and blades and chassis.  Crowbar provides orchestration that we can leverage assuming we can declare the linkages.

For now, a hack to get started…

For now, we’ve started on a workable hack for managed nodes. This involves running multiple chef-clients on the admin server in their own paths & processes. We’ll also have to add yet more roles to comprehend the relationships between the managed nodes and the things that are connected to them. Watch the crowbar listserv for details!

Extra Credit

Notes on the Opscode wiki from the Crowbar & Managed Node sessions

The 451 Group Cloudscape report strikes chord misses harmony (DevOps, Hybrid Cloud, Orchestration)

It’s impossible to resist posting about this month’s  451 Group Cloudscape report when it calls me out by name as a leading cloud innovator:

… ProTier founders Dave McCrory and Rob Hirschfeld. ProTier [note: now part of Quest] was, indeed, the first VMware ecosystem vendor to be tracked by The 451 Group. In the face of a skeptical world, these entrepreneurs argued that virtualization needed automation in order to realize its full potential, and that the test lab was the low-hanging fruit. Subsequent events have more than vindicated their view (pg. 33).

It’s even better when the report is worth reading and offers insights into forces shaping the industry.  It’s nice to be “more than vindicated” on an amazing journey we started over 10 years ago!

Rather than recite 451′s points (hybrid cloud = automation + orchestration + devops + pixie dust), I’d rather look at the problem different way as a counterpoint.

The problem is “how do we deal with applications that are scattered over multiple data centers?”

I do not think orchestration is the complete answer.  Current orchestration is too focused on moving around virtual machines (aka workloads).

Ultimately, the solution lies in application architecture; however, I feel that is also a misdirection because cloud is redefining what an “application architecture” means.

Applications are a dynamic mix of compute, storage, and connectivity.

We’re entering an age when all of these ingredients will be delivered as elastic services that will be managed by the applications themselves.  The concept of self management is an extension of DevOps principles that fuse application function and deployment. There are missing pieces, but I’m seeing the innovation moving to fill those gaps.

If you want to see the future of cloud applications then look at the network and storage services that are emerging.  They will tell you more about the future than orchestration.
