How OpenStack installer (crowbar + chefops) works (video from 3/14 demo)

July 24th 2012 Update:

This page is very very old and Crowbar has progressed significantly since this was posted.  For better information, please visit the Crowbar wiki and  review my Crowbar 2 writeups.

August 5th 2011 Update:

While still relevant and accurate, the information on this page does not reflect the latest information about the now Apache 2 released Crowbar code.  In the 4+ months following this post, we substantially refactored the code make make it more modular (see Barclamps), better looking, and multi-vendor/multi-application (Hadoop & RHEL).  If you want more information, I recommend that you try Crowbar for yourself.

Original March 14th 2011 Text:

I’ve been getting some “how does Crowbar work” inquiries and wanted to take a shot at adding some technical detail.   Before I launch into technical babble, there are some important things to note:

  1. Dell has committed to open source release the code for Crowbar (Apache 2)
  2. Crowbar is an extension of Chef Server – it does not function stand alone and uses Chef’s APIs to store all it’s data.
  3. The OpenStack components install is managed by Chef cookbooks & recipes jointly developed by Dell, Opscode and Rackspace.
  4. Crowbar can be used to simply bootstrap your data center; however, we believe it is the start of a cloud operational model that I described in the hyperscale cloud white paper.

LIVE DEMO (video via Barton George): If you’re at SXSW on 3/14 @ 2pm in Kung Fu Salon, you can ask Greg Althaus to explain it – he does a better job than I do.

Here’s what you need to know to understand Crowbar:

Crowbar is a PXE state machine.

The primary function of Crowbar is to get new hardware into a state where it can be managed by Chef.   To get hardware into a “Chef Ready” state, there are several steps that must be performed.  We need to setup the BIOS, RAID, figure out where the server is racked, install an operating system, assign IP networking and names, synchronize clocks (NTP) and setup a chef client linked to our server.  That’s a lot of steps!

In order to do these steps, we need to boot the server through a series of controlled images (stages) and track the progress through each state.  That means that each state corresponds to a PXE boot image.  The images have a simple script that uses WGET to update the Crowbar server (which stores it’s data in Chef) when the script completes.  When a state is finished, Crowbar will change the PXE server to provide the next image in the sequence.

During the Crowbar managed part of the install, the servers will reboot several times.  Once all of the hardware configuration is complete, Crowbar will use an operating system install image to create the base configuration.  For the first release, we are only planning to have a single Operating System (Ubuntu 10.10); however, we expect to be adding more operating system options.

The current architecture of Crowbar (and the Chef Server that it extends) is to use a dedicated server in the system for administration.  Our default install adds PXE, DHCP, NTP, DNS, Nagios, & Ganglia to the admin server.  For small systems, you can use Chef to add other infrastructure capabilities to the admin server; unfortunately, adding components makes it harder to redeploy the components.  For dynamic configurations where you may want to rehearse deployments while building Chef recipes, we recommend installing other infrastructure services on the admin server.

Of course, the hardware configuration steps are vendor specific.  We had to make the state machine (stored in Chef data bags) configurable so that you can add or omit steps.  Since hardware config is slow, error prone and painful, we see this as a big value add.  Making it work for open source will depend on community participation.

Once Chef has control of the servers, you can use Chef (on the local Chef Server) to complete the OpenStack installation.  From there, you can continue to use Chef to deploy VMs into the environment.  Because Chef encourages a DevOps automation mindset, I believe there is a significant ROI to your investment in learning how this tool operates if you want to manage hyperscale clouds.

Crowbar effectively extends the reach of Chef earlier into the cloud management life cycle.

3/21 Note: Updated graphic to show WGET.

Dell to spin bare iron into OpenStack gold

I’m at the CloudConnect conference today supporting my team’s initial OpenStack foray.   Our announcement part of the Rackspace Cloud Builders announcement.

Tonight (3/8), we’re at the Rackspace Launch with a pony rack of servers (6 nodes) where we will run a LIVE DEMO of our cloud installer (codename “Crowbar”).  The initial offer includes my hyperscale white paper and our cloud foundation kit.

Interested in the details?  Here are background posts that talk about the Lean/Agile process we use, what is Crowbar, and my write up about hyperscale (“flat edge”) data centers.

Added 3/9: Links to articles about the release:

Here’s what Dell is saying about OpenStack on Dell.com/openstack:

Dell is one of the original partners in the OpenStack community, which has now grown to more than 50 companies and participants. To accelerate adoption of this powerful platform, Dell has worked to develop an effortless out-of-box OpenStack experience with:
  • Optimized PowerEdge™ C-based hardware configurations
  • A technical whitepaper that details the design of an OpenStack hyperscale cloud on PowerEdge C server technology
  • An OpenStack installer that allows bare metal deployment of OpenStack clouds in a few hours (vs. a manual installation period of several days)

Read more about the steps to design an OpenStack hyperscale cloud in a Dell technical whitepaper entitled “Bootstrapping OpenStack Clouds.”

Interested?  Contact OpenStack@Dell.com.

Seattle Cloud Camp, Dec 2010

While I was in Seattle for Azure training preparing for Dell’s Azure Appliance , Dave @McCrory suggested that we also attend the Seattle Cloud Camp (SCC Tweets).  This event was very well attended (200 people!).  With heavy attendance by Amazon (at their HQ), Microsoft (in the ‘hood), and Google, there was a substantial cloud vendor presence (>25% from those vendors alone).  Notable omission: VMware.

My reflection about the event by segment.

Opening Sessions:

  • Most of the opening sessions were too light for the audience.  I thought we were past the “what is cloud” level, sigh.
  • Of note, the Amazon security presentation by Steve Rileywas fun and entertaining.
  • Picking on a Dell competitor specifically: calling your cloud solution “WAS” is a branding #fail (not that DCSWA much is better).

Unpanel of self-appointed cloud extroverts experts:

  • The unpanel covered some decent topics (@adronbh captured them on twitter), unfortunately none of the answers really stood out to me.  Except for NoSQL.
  • The unpanel discussion about NoSQL drew 2 answers.  1) It’s not NoSQL, it’s eventually consistent instead of strictly consistent.  (note: I’ve been calling it “Storage++”) 2) We’ll see more and more choices in this area as we tune the models for utility then we’ll see some consolidation.  The suggestion was that NoSQL would follow the same explosion/contraction pattern of SQL databases.

Session on Cloud APIs (my suggested topic)

  • The Cloud API topic was well attended (30+).  The vast overwhelming majority or the attendees were using Amazon.
  • There was some interest in having “standard” APIs for cloud functions was not well received because it was felt to stifle innovation.  We are still to early.
  • It was postulated but not generally agreed that cloud aggregation (DeltaCloud, RightScale, etc) is workable.  This was considered a reason to not require standard clouds.
  • CloudCamp sponsor, Skytap, has their own API.  These APIs are value added and provide extra abstraction levels.
  • It was said that there are a LOT (50 now, 500 soon) smaller hosts that want to enter the cloud space.  These hosts will need an API – some are inventing their own.
  • I brought up the concept discussed at OpenStack that the logical abstraction for cloud network APIs is a “vlan.”  This created confusion because some thought that I meant actual 802.1q tags.  NO!  I just meant that is was the ABSTRACTION of a VLAN connecting VMs together.
  • There was agreement from the clouderati in the room that cloud networking was f’ed up, but most people were not ready to discuss.
  • Cloud APIs have some basics that are working (semantics around VMs) but still have lots of wholes.  Notably: networking, application, services, and identity)

Session on Google App Engine (GAE)

  • GAE is got a lot going on, especially in the social/mobile space.
  • Do not think a lack of news about GAE means that they are going slow, it’s just the opposite.  It looks like they are totally kicking ass with a very focused strategy.  I suspect that they are just waiting for the market to catch-up.
  • GAE understands what a “platform” really is.  They talk about their platform as the SERVICES that they are offering.  The code is just code.  The services are impressive and include identity, mail, analysis, SQL (business only), map (as in Map-Reduce), prediction (yes, prediction!), storage, etc.  The total list was nearly 20 distinct services.
  • GAE compared them selves to Azure, not Amazon.

OpenStack Day 2 Aspiration: Dreaming & Breathing

Between partnering meetings, I bounced through biz and tech sessions during Day 2 of the OpenStack conference (day 1 notes).   After my impression summary, I’m including some succinct impressions, pictures, and copies of presentations by my Dell team-mates Greg Althaus & Brent Douglas.

Clouds on the road to Bexar
My overwhelming impression is a healthy tension between aspirational* and practical discussions.  The community appetite for big broad and bodacious features is understandably high: cloud seems on track as a solution for IT problems but there are is still an impedance mismatch between current apps and cloud capabilities.
As service providers ASPire to address these issues, some OpenStack blue print discussions tended to digress towards more forward-looking or long-term designs.  However, watching the crowd, there was also a quietly heads down and pragmatic audience ready to act and implement.  For this action focused group, delivering working a cloud was the top priority.  The Rackers and Nebuliziers have product to deploy and will not be distracted from the immediate concerns of living, breathing shippable code.
I find the tension between dreaming aspiration (cloud futures) and breathing aspiration (cloud delivery) necessary to the vitality of OpenStack.
[Day 3 update, these coders are holding the floor.  People who are coding have moved into the front seats of the fishbowl and the process is working very nicely.]
Specific Comments (sorry, not linking everything):
  • Cloud networking is a mess and there is substantial opportunity for innovation here.  Nicira was making an impression talking about how Open vSwitch and OpenFlow could address this at the edge switches.  interesting,  but messy.
  • I was happy with our (Dell’s) presentations: real clouds today (Bexas111010DataCenterChanges) and what to deploy on (Bexar111010OpenStackOnDCS).
  • SheepDog was presented as a way to handle block storage.  Not an iSCSI solution, works directly w/ KVM.  Strikes me as too limiting – I’d rather see just using iSCSI.  We talked about GlusterFS or Ceph (NewDream).  This area needs a lot of work to catch up with Amazon EBS.  Unfortunately, persisting data on VM “local” disks is still the dominate paradigm.
  • Discussions about how to scale drifted towards aspirational.
  • Scalr did a side presentation about automating failover.
  • Discussion about migration from Eucalyptus to OpenStack got side tracked with aspirations for a “hot” migration.  Ultimately, the differences between network was a problem.  The practical issue is discovering the meta data – host info not entirely available from the API.
  • Talked about an API for cloud networking.  This blue print was heavily attended and messy.  The possible network topologies present too many challenges to describe easily.  Fundamentally, there seems consensus that the API should have a very very simple concept of connecting VM end points to a logical segment.  That approach leverages the accepted (but out dated) VLAN semantic, but implementation will have to be topology aware.  ouch!
  • Day 3 topic Live migration: Big crowd arguing with bated breath about this.  The summary “show us how to do it without shared storage THEN we’ll talk about the API.”
Executive Tweet:  #OpenStack getting to down business.  Big dreams.  Real problems.  Delivering Code.

Note: I nominate Aspirational for 2010 buzzword of the year.

Greg PresentingBig Crowd on Day 1

OpenStack Bexar Design Summit Day 1

Yesterday, Dell sent me to be part of our OpenStack vanguard for the design summit.  The conference is fascinating and productive for the content of the sessions and even more interesting for the hallway meetings.

It’s obvious looking at the board composition that RackSpace and NASA Nova are driving  most of the development; however, the is palpable community interest and enthusiasm.  Participants and contributors showed up in force at this event.

RackSpace and NASA leadership provides critical momentum for the community.  Code is the smallest part of their contribution, their commitment to run the code at scale in production is the magic rocket fuel powering OpenStack. I’ve had many conversations with partners and prospects planning to follow RackSpace into production with a 3-6 month lag.

Beyond that primary conference arc, my impressions:

  • Core vendors like Citrix, Dell, Canonical are signing up to do primary work for the code base.  They are taking ownership for their own components in the stack.
  • Universally, people comment about the speed of progress and amount of code being generated.  Did I mention that there is a lot of code being written.
  • Networking is still a major challenge.  OpenStack (with Citrix’s Xen support) is driving Open vSwitchas a replacement for iptables management.
  • IPv6 gets lackadaisical treatment in the US, but is urgent in Japan/Asia where their core infrastructure is ALREADY IPv6.  Their frustration to get attention here should be a canary in the cloud mine (but is not).  They proposed a gateway model where VMs have dual addresses: IPv4 gets NATed while IPv6 is a pass-through. Seems to me that the going IPv6 internal is the real solution.
  • Cloud bursting is still too fuzzy a thing to talk about in a big group.  The session about it covered so many use-cases that we did not accomplish anything.  Some people wanted to talk about cloud API proxy while others (myself included) wanted to talk about managing apps between clouds.  My $0.02 is that vendors like RightScale solve the API proxy issue so it’s the networking issues that need focus.  We need to get back to the use-cases!

Executive Tweet: #openstack: Partners & Code = great progress.  Networking = needs more love

Other notes:

CAP Chasm: why clouds say “no SANank you” to SANs

My personal bias against SANs in cloud architectures is well documented; however, I am in the minority at my employer (Dell) and few enterprise IT shops share my view.  In his recent post about CAP theorem, Dave McCrory has persuaded me to look beyond their failure to bask in my flawless reasoning.  Apparently, this crazy CAP thing explains why some people loves SANs (enterprise) and others don’t (clouds).

The deal with CAP is that you can only have two of Consistency, Availability, or Partitioning Tolerance.  Since everyone wants Availablity, the choice is really between Consitency or Partitioning.  Seeking Availability you’ve got two approaches:

  1. Legacy applications tried to eliminate faults to achieve Consistency with physically redundant scale up designs.
  2. Cloud applications assume faults to achieve Partitioning Tolerance with logically redundant scale out design.

According to CAP, Legacy and cloud approaches are so fundamentally different that they create a “CAP Chasm” in which the very infrastructure fabric needed to deploy these applications is different.

As a cloud geek, I consider the inherent cost and scale limitations of a CA approach much too limited.   My first hand experience is that our customers and partners share my view: they have embraced AP patterns.  These patterns make more efficient use of resources, dictate simpler infrastructure layout, scale like hormone-crazed rabbits at a carrot farm, and can be deployed on less expensive commodity hardware.

As a CAP theorem enlightened IT professional, I can finally accept that there are other intellectually valid infrastructure models.

See Mom?  I can play nicely with others after all.

Clouds & Water (Blog Action Day)

Today Change.org is coordinating Blog Action Day 2010 to raise awareness about Water.  It is widely reported (and worth repeating) that scarcity of clean water is more likely to impact your daily life than scarcity of energy, food, shelter or other basic human rights.

Water scarcity has little impact in my daily life.  <shameless plug>While The new cloud servers my employer, Dell, sells consume less power and thereby less cooling water; these efficiencies do relatively little to impact people’s access to fresh water.</shameless plug>

However, waste is a huge impact.  Since Americans are water, food and energy hogs, we are also in the position of wasting disproportionate amount of these limited resources.  I believe that we commit this waste unconsciously without any real gauge on its volume or impact.  Imagine the impact to your driving behavior if you had to fill your gas tank up a cup of gas at a time (64), water your lawn from a 5 gallon bucket (30+) or refill your toilet with a table-spoon (409!).

The key to addressing waste in the land of plenty is to measure and show impacts.  I believe that people abhor waste when they see it.  Our challenge is not to change people, but to show them in real terms the consequences of their choices.

For example, just having an MPG calculator on our cars has changed the way that we drive them.  I am personally disappointed with how little useful feedback these gauges provide, but it’s a start.

One of the things I like about Cloud Computing is that we want to measure and reduce waste.  We get mad about waste: wasted computer time, wasted equipment, wasted power, and especially wasted time.

As we make strides to make computing and information more personal and mobile, I believe we need to include ways to show people data about the choices that they are making.  So next time you water your lawn or flush your toilet, this about what it would mean if you had the haul that water in a bucket up from a well.  Sound crazy?  That’s status quo for more people than those of us that enjoy indoor plumbing.

Juxtaposition: Dave McCrory joins Dell Cloud Team & Quest acquires Surgient

Rarely in my life have I seen true juxtaposition as in the last few weeks.  Mearly hours after my long time friend and cloud conspirator, Dave McCrory, joined our team at Dell; the company that we founded, Surgient, was aquired by Quest software.  Neither of us had been there for years and had been looking for ways to work together again.  Apparently the cosmos required that we could not join forces while our first effort together was still standing.

Cloud Walker

Our cloud team at Dell is full of people who like to both dream and do.  Now that we added Dave, I am expecting BIGGER things.  We’re actively planning coordinated blogging about some of the issues and inspirations that are driving our plans.   Those topics include Dev-Ops, PaaSvsIaaS, and the real “private” cloud.

Dave, welcome back to the party!

Here’s what Dave posted:

A lot has occurred since my last blog post. I am continuing the development of my technology and working in the Cloud, however I have chosen to do this with a great team at Dell. I was approached a while back about this opportunity and as I dug deeper and saw the potential I began to buy in. Finally after meeting the great team of experts involved behind the scenes I decided to join them.
I have worked with some of the team members before including Rob Hirschfeld. Rob and I founded both ProTier (note that PODS ran on VMware’s ESX) and co-founded Surgient together (interestingly Surgient announced its acquisition by Quest Software last week). Rob and I have created a great deal of IP (Intellectual Property) in the past together, including the First Patent around Cloud Computing (This was filed as a Provisional Patent in 2001 and a Full Patent in 2002). Our time at Dell should produce some new and great work in the Applied Architectures and Intellectual Property sides.

Microsoft & Dell partner for Azure hosting

Vacation rental in Fort Walton Beach, FLA

Interesting juxtaposition, last week I was vacationing at the Azure condos in Florida and this week Dell is making a strategic announcement to develop a Dell-powered Microsoft Windows Azure Platform Appliance, as well as Azure based services delivered by Dell Services.

Press Release: http://content.dell.com/us/en/corp/d/press-releases/2010-07-12-dell-microsoft-cloud-azure-appliance.aspx

This is a project that I’m involved in, so watch for updates as details emerge.

Dell goes to the Clouds (hardware & Joyent)

As a Dell employee, I’ve had the privilege of being on the front lines of Dell’s cloud strategy.  Until today, I have not been able to post about the exciting offerings that we’ve been brewing.

Two related components have been occupying my days.  The first is the new cloud optimized hardware and the second is the agreement to offer private clouds using Joyent’s infrastructure. Over the next few weeks, I’ll be exploring some of the implications of these technologies.  I’ve already been exploring them in previous posts.

Cloud optimized hardware grew out of lesson learned in Dell’s custom mega-volume hardware business (that’s another story!).  This hardware is built for applications and data centers that embrace scale out designs.  These customers build applications that are so fault tolerant that they can focus on power, density, and cost optimizations instead of IT hardening.  It’s a different way of looking at the data center because they see the applications and the hardware as a whole system.

To me, that system view is the soul of cloud computing.

The Dell-Joyent relationship is a departure from the expected.  As a founder of Surgient, I’m no stranger to hypervisor private clouds; however, the Joyent takes a fundamentally different approach.  Riding on top of OpenSolaris’ paravirtualization, this cloud solution virtually eliminates the overhead and complexity that seem to be the default for other virtualization solutions.  I especially like Joyent’s application architectures and their persistent vision on how to build scale-out applications from the ground up.

To me, scale should be baked into the heart of cloud applications.

So when I look at Dell’s offings, I think we’ve captured the heart and soul of true cloud computing.
